A240 Type 316H Stainless Steel PLATE

 A240 Type 316H Stainless Steel PLATE

 A240 Type 316H Stainless Steel PLATE

1.Stainless Steel Plate

Type 304 | Type 304L | Type 304H | Type 316 | Type 316L | Type 316H | Type 321 | Type 347

Type 410 | UNS S32205 Duplex | UNS S32750 SuperDuplex | UNS S32760 SuperDuplex

2.316H, with higher carbon content, displays excellent resistance to increased working temperatures. Type 316H is a higher carbon variant of 316 making the steel more suitable for use in applications where elevated temperatures are present. Stabilised Grade 316Ti offers similar qualities.

3.The increased carbon content delivers a greater tensile and yield strength. The austenitic structure of the material also gives this grade excellent toughness, even down to cryogenic temperatures.

4.The steel lends itself well for use in the petrochemical, gas and chemical industry. Masteel supply Grade 316H to a variety of customers including fabricators of pressure vessels, industrial boilers and heat exchangers.

5.Benefits of using Type 316H Stainless Steel

Increased carbon content heat resistant qualities

Greater tensile yield strength

Greater short and long term creep strength

6.Chemical Composition

UNS No Grade C Si Mn P S Cr Mo Ni N
S31609 316H 0.04/0.10 0.75 2.00 0.045 0.030 16.00/18.00 2.00/3.00 10.00/14.00 ––

7.Mechanical Properties

UNS No Grade Proof Stress
0.2% (MPa)
Tensile Strength
(MPa)
Elongation
A5(%)
Hardness Max
HB HRB
S31609 316H 205 515 40 217 95

8.For more information about 316H stainless steel and the services that We can offer,  please contact us.
